The MARIO series boasts a robust construction featuring high-strength aviation aluminum alloy components and T300 3K carbon fiber plates. Designed to meet DJI 03 VTX ultra-wide-angle requirements, the alloy head ensures lens protection and delivers impressive visual clarity. With features like a recessed GoPro mount for improved stability and a unique carbon plate arm support structure, the MARIO series offers enhanced body stability and minimized twisting during flight. Additionally, selectable dual main power inputs allow for easy adjustment of the drone’s center of gravity. The frame provides ample space for receiver installation and encourages customization with diverse OpenSource 3D models.

Features:

1. High-Strength Alloy Head: Protects the lens and meets DJI 03 VTX ultra-wide-angle requirements.
2. Recessed GoPro Mount: Lowers the center of gravity for improved stability.
3. Unique Support Structure: Enhances body stability and accommodates capacitor installation.
4. Power Dual Input Method: Allows for easy adjustment of the drone’s center of gravity.
5. Frame Protection Armor: Provides front protection for the FC and enhances DJI 03 heat dissipation.

Specifications:

1. Top Plate Thickness: 2.5mm (T300 3K)
2. Middle Plate Thickness: 2.0mm (T300 3K)
3. Bottom Plate Thickness: 2.5mm (T300 3K)
4. Arm Thickness: 6mm (T300 3K)
5. Camera Mounting Screw: 7mm
6. Compatible Propeller Size: Max 5.1 Inch
7. Motor Mounting Hole Distance: 16-19mm
8. FC Mounting Hole: 30.5X30.5(M3)
9. VTX Mounting Hole: 20X20(M2) / 25.5X25.5(M2)
10. Head Material: Aviation Aluminum Alloy
11. Aluminum Column Material: 7075 D523mm/D4622mm
12. Internal Mounting Height: 23-31mm

Package Includes:

1 x SpeedyBee Mario 5 DC Pro Frame
